Ludy, Llewellyn V., 1875- [from old catalog], American Technical Society · Chicago, American technical society · leaf 96
he outer end ofthe shaft then weighs Wx pounds, the brake horsepower formulawould be b.h.p. = .0001904 RNiW-WJ Speed Counter. In finding the b.h.p. or i.h.p. of an engine,it is necessary to know the number of revolutions the engine makes ina minute. This speed is usually designated as r.p.m. In… … Fig. 69. Standard Form of Speed Counter The actuating motion of the engine or other machine to whichthe counter is to be attached, is generally communicated by a rodor bar moving in the same general direction of its length, and thelever should be connected to such rod at a right angle when suchrod…
Indicators for steam-engines · Steam-engines
