Creighton, William Henry Paul, 1859- · New York, J. Wiley & sons; [etc., etc.] · leaf 110
tto scale) showing the relative crank and eccentric positions forany valve position. When the entering steam occupies the space S the outsidelap is called steam lap and the inside lap is exhaust lap. Thesenames are reversed if the entering steam occupies the space E.It is not necessary for the…
Steam-engines · Heat-engines
