The steam-engine and other heat-motors (1909)
Creighton, William Henry Paul, 1859- · New York, J. Wiley & sons; [etc., etc.] · leaf 146
Fig. 88. VALVE-DIAGRAMS AND SLIDE-VALVES. High_Pressure Cylinder 12 x 20175 Rev.per Minute 125 … Fig. 89.Steam-engines · Heat-engines
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
