Creighton, William Henry Paul, 1859- · New York, J. Wiley & sons; [etc., etc.] · leaf 343
Maximum pressureduring admission. CD Eatio of Expansion = -j-^-, … Com.on Eng. Tests Fig. 166. first by the ratio of the length of the high-pressure diagram to thedistance AB, and then by the ratio of the distance CD to thelength of the low-pressure diagram. Diagram Factor.—The Committees definition of the DiagramFactor was given in the case of simple engines. In…
Steam-engines · Heat-engines
