n producedby this movement of the link are the same as those produced by aswinging eccentric. REVOLUTION CONTROL. 353 On locomotives, owing to the relative positions of the valve(above the cylinder and outside the driving-wheels) and the eccen-trics (on the driving-axle and inside the… … Fig. 184.—Marine Engine. center of the backing eccentric is at E. The link-pins P and Pf arebehind the link; the saddle-plate m0 is dished to pass over thelink-block, B, when the link is raised to bring the eccentric, Ef,into full gear. The link is suspended on one side by the hanger?w?o from the…
