The steam-engine and other heat-motors (1909)

Creighton, William Henry Paul, 1859- · New York, J. Wiley & sons; [etc., etc.] · leaf 143

An illustration from The steam-engine and other heat-motors, 1909, leaf 143 — Fig. 81.—Loss by Cylinder-condensation … Fig. 82.—Typical Admission-Lines. (From Carpenters Experimental Engineering.) VALVE-DIAGRAMS AND SLIDE-VALVES. 123 Top of cylinderSteam side. Bottom of cyQnderSteam side.

Steam-engines · Heat-engines
