Creighton, William Henry Paul, 1859- · New York, J. Wiley & sons; [etc., etc.] · leaf 195
Fig. 108.—Carpenters PatentThrottling-calorimeter. Standards. Steam at high pressure contains more heat than anequal weight of steam at low pressure. Y\Tien steam is allowed 174 THE STEAM-ENGINE AND OTHER HEAT-MOTORS. to expand suddenly from a high to a low pressure, forming eddiesand doing no… … any moisture the first effect is to convert the moisture into steamat the lower pressure. If there is still an excess of heat, then allthe steam at the lower pressure will be superheated until the excessis absorbed. In Fig. 108 the steam passes through the sampling-nozzle MEASURING EFFECTS OF HEAT…
Steam-engines · Heat-engines
