Creighton, William Henry Paul, 1859- · New York, J. Wiley & sons; [etc., etc.] · leaf 372
, but also through a port-passagein the valve itself. Draw the Zeuner or Bilgram diagrams for the following examples. Ex. 119. Width of port, 5/8 in.; length of port, 12 in.; steam-lap,9/16 in.; exhaust-lap: head end —1/8 in., crank end 0 in.; L/R=6:eccentric-arm infinite; engine, 14X20; 210… … 352 THE STEAM-ENGINE AND OTHER HEAT-MOTORS. length of eccentric or swinging arm, 14 in.; its center is on the line ofcenters of shaft and crank-pin when the latter is on a dead-center. Ex. 121. Width of port, If in.; length, 8 in.; 9X10 engine;300 revolutions; steam-lap, 1 in.; exhaust-lap, 5/16…
Steam-engines · Heat-engines
