00 pounds; cut-off, 3/4 stroke; jet condenser, 26vacuum; 125 revolutions; lead, 1/16; maximum port-opening, 3/4.Connecting-rod = 5 cranks. Assume position of reverse-shaft andother required data. Buckeye Engine.—Fig, 191 is a cross-section of a tandemcompound engine of the Buckeye type. The valve… … 0 — a REVOLUTIOX CONTROL. 363 place at the ends. Admission of steam is practically controlledby the cut-off valve, while exhaust is controlled by the mainvalve alone. The main valve-stem is hollow and the cut-offvalve-stem works through the main valve-stem. Fig. 192 illustrates the valve-gear…
