Creighton, William Henry Paul, 1859- · New York, J. Wiley & sons; [etc., etc.] · leaf 403
he crank-position, prolonged if necessary and drawing a parallel to thenew connecting-rod position as PfT was drawn, the tangentialpressure for the new crank-position will be indicated by thedistance between 0 and the point of intersection of the paralleland the line OM. It is not necessary to find… … Fig. 208. lay off the tangential pressure radially—at right angles to itstrue position—from the center of the crank-pin. CT, for instance,is equal to OT. Join the points so found. The area enclosedby this line and the perimeter of the circle does not measure work.2. (Fig. 209.) A much more useful…
Steam-engines · Heat-engines
