Fig. 38. Steam Pressure 105 PoundsRevolutions 250Spring 60 … Figs. 39 and 40. . STEAM-ENGINE INDICATOR A.\lD ITS CALIBRATION. 67 they occur at uniform arc distance apart. This shows that thesudden impingement of the steam on the indicator piston pro-duces an harmonic vibration similar to that just described.(Figs. 39 and 40.) All cards from high-speed…
