Steam engines, prepared in the Extension division of the University of Wisconsin (1919)
Shealy, Edward Marvin · New York, McGraw-Hill · leaf 107
crankend while exhaust is taking place from the head end. 92 STEAM ENGINES Besides being used to determine the power developed by anengine, the indicator diagram also shows whether or not theengine and indicator are adjusted properly. Faults in the engineadjustment will be considered in a later… … Fig. 61. completed its stroke. It will be seen that the left-hand ends ofboth diagrams appear to be cut off, the heel of one diagram andthe toe of the other being cut off on the same Une. The samefault may be caused by the motion of the crosshead not beingreduced sufficiently, but in this case the…
Steam-engines
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
