An illustration from Steam engines, prepared in the Extension division of the University of Wisconsin, 1919, leaf 150 — Fig. 75. should be noted that the eccentric may be set either in the posi-tion Oe, Fig. 75, or in the position Od, and the engine will runeither in a clockwise or counterclockwise direction of rotation,depending upon the direction in which it starts. The onlyrequirement in setting the eccentric for…
