Steam engines, prepared in the Extension division of the University of Wisconsin (1919)
Shealy, Edward Marvin · New York, McGraw-Hill · leaf 219
Fig. 132. The manufacturers of Corliss engines usually place a mark A,Fig. 133, on the hub of the wrist plate and three marks D, B, andC on the wrist plate stud. When A coincides with B the wrist B c _z ■^ 7^~^ … D Fig. 133. plate is in its central position, and in this position the rockerarm and eccentric should be vertical, and if they are not verticalthe length of the eccentric and reach rods should be adjusted CORLISS VALVE GEARS 205 until they are vertical. When A coincides with D the wristplate is at…
Steam-engines
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
