Steam engines, prepared in the Extension division of the University of Wisconsin (1919)
Shealy, Edward Marvin · New York, McGraw-Hill · leaf 61
ng the wedge-shaped block up-ward, thus forcing the brasses closer together. By having oneof the adjusting wedges placed on the inside of the end and theother placed on the outside of the end, the length of the connect-ing rod, which is the distance from the center of the wrist pinto the center of… … Fig. 35. strap passes around the brasses and laps over the end of the rodat top and bottom. The strap is fastened to the connectingrod by means of two bolts which pass entirely through bothends of the strap and through the connecting rod and are securedby a nut and lock nut. Keys are inserted…
Steam-engines
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
