Steam engines, prepared in the Extension division of the University of Wisconsin (1919)

Shealy, Edward Marvin · New York, McGraw-Hill · leaf 64

An illustration from Steam engines, prepared in the Extension division of the University of Wisconsin, 1919, leaf 64 — engines, are illustratedin Figs. 41 and 42. In Fig. 41the bearing is divided along aline making about 45 degreeswith the horizontal. The lower part has a flat plate cast on itsouter surface which rests in the frame and which may be adjustedvertically by shimming, or placing thin sheets of metal… … Fig. 40.

Steam-engines
