Steam engines, prepared in the Extension division of the University of Wisconsin (1919)
Shealy, Edward Marvin · New York, McGraw-Hill · leaf 64
Fig. 40. … Fig. 41. the flat plate at the side. The cap rests on the flat plate at thetop and is held in place by bolts passing down into the frame.The bearing is lined with babbitt metal having a series ofdiagonal grooves cut in it for distributing the oil throughout thelength of the bearing. The bearing…
Steam-engines
