Steam engines, a thorough and practical presentation of modern steam engine practice (1920)
Ludy, Llewellyn V., 1875-, American Technical Society · Chicago, American technical society · leaf 88
Fig. 52, is transmitted through therod M to the water piston in the cylinder R. As the piston moves STEAM ENGINES 73 back and forth, water enters through the intake valves 0 and leavesthrough the discharge valves immediately above, and finally leavesthrough the delivery pipe P. In order to create a… … Fig. 52. Section of Duplex Pump with Tappet SPECIAL ENGINES Under this heading may be placed a large number of engineswhich have been built for a very definite field of usefulness, such asvarious types of fire engines and automobile engines, where steamis used as the motive force. Again.a number of…
Steam-engines
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
