Ripper, William, 1853-1937 · London, New York [etc.] : Longmans, Green and co. · leaf 112
peeds the length isreduced. The movement of the drum is obtained by some arrange-ment for reducing the motion of the crosshead in the folloAvingratio, namely— (length of diagram required) -f- (length of stroke o£ engine) The method of obtaining the movement required differs accordingto the design… … Fid. 101. 96 STEAM-ENGINE THEORY AND PRACTICE. Fig. 102 shows a method of fitting up an indicator gear for a small vertical engine, as used bythe author for experimentalpurposes. Figs. 103-107 show-other methods, as apphed tohorizontal engines. The pointsrequiring special attentionare— (1) The…
Steam-engines
Internet Archive · California Digital Library · Public Domain Mark 1.0. Free to use for anything.
