Ripper, William, 1853-1937 · London, New York [etc.] : Longmans, Green and co. · leaf 199
ts of space. The tubes are made to pass right throughthe condensing chamber, and so as to permitof no connection between the steam andcondensing water. The steam is exhaustedinto the condenser, and there comes in con- J tact with the cold external surface of the tubes. It is then condeiised, falls… … CONDENSERS. 183 covers are placed over each end, space being left to allow of circulationof the cooling water as shown by the arrows. The cooling water is forced through the tubes by means of a
Steam-engines
