Ripper, William, 1853-1937 · London, New York [etc.] : Longmans, Green and co. · leaf 202
to give steam to the other, after whichit finishes its own stroke, and waits for its valve to be acted upon CONDENSERS. 185 before it can renew its motion. This pause allows all the valves toclose quietly, and prevents shocks. One or other of the valves isalways open, and there can therefore be no… … Fig. 201. A feature of this condenser is the double-tube system of con-veying the cooling water, as shown in Fig. 202. The circulating orcooling water enters at the outer end of the smaller internal tubes,which extend nearly to the far end of the larger tubes. The smalltubes are open at the inner…
Steam-engines
