Ripper, William, 1853-1937 · London, New York [etc.] : Longmans, Green and co. · leaf 344
o that constantlubrication is ensured. A cast-iron die-piece is held by set screwsbetween the side levers, and the governormotion is transmitted therefrom to the cut-oftgear. The communicating mechanism betweenthe lifting lev^ers C and D and the cut-offspindle L is arranged so that the valve gearis… … Fig. 380. F comes into contact with the small inclined lever G and moves thedetaching lever so that the trigger cannot engage the trip lever, andthe engine is stopped. Another lever, H, is also provided, to the end of which a cord isattached, which is connected electrically or otherwise to the…
Steam-engines
