Cyclopedia of textile work : a general reference library on cotton, woollen and worsted yarn manufacture, weaving, designing, chemistry and dyeing, finishing, knitting, and allied subjects (1907)

Chicago : American school of correspondence · leaf 37

An illustration from Cyclopedia of textile work : a general reference library on cotton, woollen and worsted yarn manufacture, weaving, designing, chemistry and dyeing, finishing, knitting, and allied subjects, 1907, leaf 37
Fig. 14. The hub of the leese gear is cut in the form of a worm, witha slot in it, and at every turn of the hub a catch point on a smalllever drops in the slot. This lever is connected with the shipperrod, so that when the machine is stopped a bell is rung. If morethan 1,000 yards are required, say…

Textile industry · Textile fabrics

Internet Archive · UMass Dartmouth, Claire T. Carney Library · Public Domain Mark 1.0. Free to use for anything.
