Ripper, William, 1853-1937 · London, New York [etc.] : Longmans, Green and co. · leaf 354
lly return and the port beclosed when the piston is at some point, 6, near the end of the strokeas with an ordinary slide-valve without lap, but in that case thespecial feature of the Corliss gear would disappear, as it was designedto provide an efficient means of obtaining a range of early… … N\\\\\\VVVVV\V\\<\J>S?^ Fig. 390. double wrist-plate : one for tlie admission valves and the other forthe exhaust valves, as shoAvn in Figs. 390 et seq. Considering further the case of the single eccentric, frdin Fig.384, it will be seen that the wrist-plate pin, F, travels through an arcdd…
Steam-engines
