e air-escape plug.The details of the other parts of the gear explain themselves. Diagram of Steam-valve Movements. —Fig. 397 shows a geo-metrical analysis ofthe movements of thesteam-admission valvegear. Arcs A, B, C,and D represent re-spectively clearancemovement of valvelever to effect…
