Steam-engine theory and practice (1922)
Ripper, William, 1853-1937 · London, New York [etc.] : Longmans, Green and co. · leaf 363
Fig. 402. compound hoinzontal Corliss engines, made by Messrs. Hick, Hargreaves& Co., of Bolton. Diameter of piston, high pressure :^Oin. „ low pressure 5G „ Diameter of piston-rods 6 ., Stroke 5 ft. Clearance of high-pressure cylinder 4 per cent Clearance of low-pressure cylinder 5 Diameter of… … :^?:rT^^^^r^T^^7?7Tr Fig. 403.Steam-engines
