Practical mechanical drawing and machine design self taught .. (1907)
Westinghouse, Charles. [from old catalog] · Chicago, F. J. Drake & co. · leaf 138
and are supported at theback of the engine on three hollow cast-iron col-umns cast on the condenser. At the front thecylinders are supported by two turned wrought-iron columns, which are flanged at their upperends, and firmly secured at their lower ends tothe bed of the engine. The guides for the… … Fig. 211—Triple Espansiou Marine Engine, End Elevation. 136 MECHANICAL DRAWING and are 4 feet 11 inclies apart. The circulating orcooling water enters the condenser at the bottom,and passes through the lower nest of 114 tubes,and back through the upper nest of 114 tubes.The cover on one end of the…
Mechanical drawing · Machine design
