d-position = Ci.conaec ting-rodfrom centre on haproduced, also givethe piston displace-ments 0/ and 0{j= Cu and Ci; re-spectively. Thedistance vn mea-sures the deviationof the piston forjjositions C or C ofthe crank due tothe obliquity of theconnecting-rod. Zeuner ValveDiagram,—Thisdiagram was… … Fig. 64.It will be best understood by reference to the following figures 68 STEAM-ENGINE THEORY AND PRACTICE. Ill Fig. 65, let ah be the travel of the slide-valve, Oa the crankposition, and OE the position of the centre line of the eccentric,
