Ripper, William, 1853-1937 · London, New York [etc.] : Longmans, Green and co. · leaf 94
the link, and the rods are attached to thenearest end of the link, as shown in Fig. 79, the rods are said tobe open. This is the usual way of connecting the eccentric rodsto the link. When the crank is in the same position as before, andthe rods are connected to the end of the link on the opposite… … Jig. 78. 78 STEAM-ENGINE THEORY AND PRACTICE. link approaches its mid-position; with crossed rods the reverse isthe case. This is iUustrated more fully in Figs. 86 and 88. The paths of the moving parts of the link motion during a revo-lution of the crank are compounded of the movement due to…
Steam-engines
