s the centre of the shaft, and CP1P3 in Fig. 82 is drawn to anenlarged scale in Fig. 8.3. Take positions Pj, Pg, Pn, and draw circleson the diameters CPj, CP„, CPo; then, for position CPj in full forwardgear, cut-off takes place at Cj, drawn through the intersection of the THE SLIDE-VALVE. 8i lap… … Fig. 82. Fig. S3. as of release, compression, and admission, may be traced in thesame way. K p _-—-^^ 1 u ^ ~M ^ \ - ,1, \ 0 y -^ - aL valift rod Fig. 84. Equivalent Eccentric, with Oblique Connecting-rods.—In Fig. 84,let OC represent the crank, and OE the eccentric with angularadvance KOE, and BD…
