Ripper, William, 1853-1937 · London, New York [etc.] : Longmans, Green and co. · leaf 99
Fig. 85. Fig. 86. radius Of of the equivalent eccentric is a little increased. By drawingEE at right angles to OE, then the line joining O to E and makingan angle a with OE is the equivalent eccentric required. Referring to Fig. 85, OF is the resultant eccentric for the end Dof the link. If the…
Steam-engines
