The steam engine and turbine; a text-book for engineering colleges (1911)
Heck, Robert Culbertson Hays, 1870- · New York, D. Van Nostrand company · leaf 334
thod uses the computed values of the ratio of T to P, or of m = —-—, given in Table 15, working through a reduction cos j8 or proportion diagram like those in Fig. 81. The base line AB, Fig. 176, is taken of any convenient length, and along the perpendiculars AC § 32(e)] WORKING FORCES IN THE… … Fig. 175. — Turning-force Diagram. series of lines, values belonging to quadrants I and IV are laid up onAC, those for quadrants II and III on BD. Then the inclined linesare drawn: and for any particular crank angle, as20deg., we have only
Steam-engines · Steam-turbines
