The steam engine and turbine; a text-book for engineering colleges (1911)
Heck, Robert Culbertson Hays, 1870- · New York, D. Van Nostrand company · leaf 354
c. ^ -0 /K J, A … Ci 180 H H Fig. 195. — Diagrams of Shifting Force. In Fig. 195 II, the diminution of OCi and OC2 by CJi and C2J2,each equal to Fb, is shown with the purpose of giving a clear idea ofthe size of the primary forces. Then the resultant OK is the radius inI; while CK, the same as OB in Fig. 194 II, is…
Steam-engines · Steam-turbines
