the Stephenson gear, Fig. 242. (h) Geometrical Relations. — At I in Fig. 251, B0D0 is the mid-dle position of the link, with crank on dead center, while Bp is the sameas in Fig. 249. Let eccentric radius OE = r, DP = k0, BP = k, alsolet maximum BP upward = ki and maximum BP downward = /c2.The…
