The steam engine and turbine; a text-book for engineering colleges (1911)
Heck, Robert Culbertson Hays, 1870- · New York, D. Van Nostrand company · leaf 466
d between the radiallines CA and CB, the same center Cbeing used for the arcs through Dand E. The straight lines (tangents)which form a large part of the outerprofile of the vane section have, ofcourse, the inclination of the velocity V\ as in Fig. 318, making theangle ai with the line CD. An… … Fig. 320. — Element of Curtis Turbine. 450 ACTION OF THE STEAM IN THE TURBINE. [Chap. IX. of velocity due to abstraction of energy — this on the assumption thatthe velocity changes are according to a diagram like Fig. 322, where Aremains constant. Only for the purpose of accommodating extra…
Steam-engines · Steam-turbines
