Mechanical equipment of buildings; a reference book for engineers and architects (1916)

Harding, Louis Allen, Willard, Arthur C. (Arthur Cutts), 1878-1960 · New York Wiley · leaf 330

An illustration from Mechanical equipment of buildings; a reference book for engineers and architects, 1916, leaf 330 — Hi 338 SfcK MLjr Stea rtrriTral … Fig. 18. Curtis Turbine—Few Pressure Stages—Two Fig. 19. Rateau Turbine—Multiple-Pres-Velocity Stages for Each Pressure Stage. sure Stages—Single-Velocity Stage. This heat, except for a small fraction that is radiated, is expended in raising the quality of thesteam (or superheating it). The quality…

Building · Heating · Ventilation

Internet Archive · University of Toronto, Robarts Library · Public Domain Mark 1.0. Free to use for anything.
