The steam engine and turbine; a text-book for engineering colleges (1911)
Heck, Robert Culbertson Hays, 1870- · New York, D. Van Nostrand company · leaf 535
Fig. 358. — Sections ofDe Laval Discs.I, Rotor of largerturbines; II, Detailof shaft fasteningin Fig. 18. 518 DESIGN AND CONSTRUCTION OF THE TURBINE. [Chap. X. … Fig. 359. — Detail of Curtis Turbine, showing construction of wheel. From cur-rent catalogue, General Electric Company. Example 53. — To get some idea of the magnitude of the centrifugal forceon a high-speed turbine wheel, take the cases of (1) a 4-in. wheel at 30,000 r.p.m.and (2) a 30-in. wheel…
Steam-engines · Steam-turbines
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
