The steam engine and turbine; a text-book for engineering colleges (1911)
Heck, Robert Culbertson Hays, 1870- · New York, D. Van Nostrand company · leaf 321
— In Figs. 164 and 165 areshown the two typical conditions, for the first and second quadrants,respectively, of the crank motion. In quadrant I, OB/OC is greaterthan sin a, in quadrant II it is less: while for infinite rod, CB wouldbe horizontal and the motion symmetrical with respect to the… … Fig. 166. — Derivation and Form of the Diagram of Piston Velocity. In Fig. 166, the radius OC is taken to represent, on a convenientscale, the intensity of the (constant) velocity Vo of the crank pin; then,directly from Fig. 165, the rod line WC cuts off, in OD, the length ofthe piston velocity. It…
Steam-engines · Steam-turbines
