type, and is puton to-keep the governor from responding too freely to small and irregu-lar impulses. The governor rocker 8 is the piece numbered 13 onFig. 267. Action of the Safety Cams. — In Fig. 268 the whole mechanism isdrawn in the starting position (for the engine standing idle), with thearm L… … Fig. 270. — Diagram of the Valve Gear. has lifted, has a part of its upper edge cut away, as shown at C on Fig.268. When the engine is running, this notch is to be brought underL; then if through accident to its belt or for some other reason thegovernor ceases to turn, the balls will drop below the…
