The steam engine and turbine; a text-book for engineering colleges (1911)
Heck, Robert Culbertson Hays, 1870- · New York, D. Van Nostrand company · leaf 455
Fig. 307. — Resolution of Centrifugal Fig. 308. — Combining the Impulses. Force. vane or bucket. Resolving any elementary force /c, we get the drivingcomponent /t = /c cos a, and the axial component /a = /c sin a, thelatter being parallel to the axis in the usual type of axial-flow turbines.To get…
Steam-engines · Steam-turbines
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
