The steam engine and turbine; a text-book for engineering colleges (1911)
Heck, Robert Culbertson Hays, 1870- · New York, D. Van Nostrand company · leaf 561
From ENGINEmT T M y WaterLJ Level FromPump … Fig. 387. — Simple Jet Condenser. Fig. 388. — Barometric Condenser. (c) Removal of Condensate. —The jet condenser can be evacu-ated without the use of a vacuum pump: one scheme is illustrated inFig. 388, the other, the ejector condenser, can be described in a fewwords. The barometric condenser is…
Steam-engines · Steam-turbines
