Ui PLANS AND SECTIONS OF ENGINE. … views of a loco-motive engine onthree pairs ofwheels with itstender, is givenin figs. 7,8,9,10,11,12,13, andl4. Fig. 7 is alongitudinal ver-tical section,made by a planeparallel to thewheels, and pass-ing through theaxis of the boilerand the smoke-funnel. Fig. 8 is aplane of theworking machi-nery…
Steam-engines · Steam-navigation · Locomotives
