Locomotive text for engineers and firemen; a complete treatise on the engine, electric head-light and standard code of train rules (1908)
National correspondence school of railroading, Chicago. [from old catalog] · [Chicago] · leaf 150
PLATE 37. LOCOMOTIVE LUBRICATORS. 139 Operation. To fill the lubricator filler plug O, Plate36, should be removed and the reservoir filled with cleanstrained valve oil. If there is insufficient oil to fill thereservoir, add enough water to make up the requiredquantity. This will enable the feeds to… … PLATE 38 To start the lubricator it should first be ascertainedthat the boiler valve is open, after which steam valve Bat the top of condenser F should be opened and allowedto remain open while the lubricator is in operation. 140 LOCOMOTIVE LUBRICATORS. Sufficient time should be allowed for the…
Locomotives
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
