Steam power plant auxiliaries and accessories; (1922)
Croft, Terrell, 1880- ed, Dufflin, Daniel John, 1911- ed · New York, [etc] McGraw-Hill book company, Inc · leaf 185
Inch Fig. 183.—Limiting And Overflowing Temperatures. (This figure was takenfrom page 135 of Kneass Practice And Theory op the Injector.) peratures affect delivery temperature of feed-water, capacity of injectorand pounds of water pumped per pound of steam. The height of suc-tion lift affects the… … Inlet Water Temperature °FFig. 184.—Test Results Of A Sellers No. 8 Self-Adjusting Injector. Fig. 186 shows the variation in capacity of the same Penberthy Injectoroperating under different steam pressure but with the height of lift andinlet water temperature constant at 4 feet and 74 deg.…
Steam power plants · Pumping machinery
