Steam power plant auxiliaries and accessories; (1922)
Croft, Terrell, 1880- ed, Dufflin, Daniel John, 1911- ed · New York, [etc] McGraw-Hill book company, Inc · leaf 194
mical For Feeding Boilers InA Plant Not Equipped With Means Of Feed-Water Heat-ing.—Under this condition the injector (Fig. 193) acts as a com-bined pump and pre-heater; and, as such, is almost 100 percent, efficient. The conditions favorable to injector installa-tion often obtain in temporary or… … Fig. 193.—An Inspirator Type Of Injector Piped Up For Boiler Feeding. feature of pre-heating its feed water, makes the injector addi-tionally valuable where cold water is to be fed into the boiler.By pre-heating, the strains which cold water would cause inthe boiler are avoided. The proper…
Steam power plants · Pumping machinery
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
