Steam power plant auxiliaries and accessories; (1922)
Croft, Terrell, 1880- ed, Dufflin, Daniel John, 1911- ed · New York, [etc] McGraw-Hill book company, Inc · leaf 231
^To Feed Pump -Hot Wafer Fig 219.—Diagram Of Open Feed-Water Heater. Safety ValveFeed Outlet^ Connection--j> … Fig. 220.—Blake-Knowles Water-Tube Type Of Closed Exhaust-Steam Feed-Water Heater. (The water passes through each of the six tube nests in turn,thus traversing the heater six times. The steam passes three times through theheater.) an open heater, the temperature of the feed water can—assuming that…
Steam power plants · Pumping machinery
