Steam power plant auxiliaries and accessories; (1922)
Croft, Terrell, 1880- ed, Dufflin, Daniel John, 1911- ed · New York, [etc] McGraw-Hill book company, Inc · leaf 243
—Typical Installation Of Open Feed-Water Heater Pipes For InductionOperation In Connection With Vacuum Heating Plant. arrangement, if more steam is received than can be condensedin the heater, the excess passes through the heater to theatmosphere or heating system. 222 STEAM POWER PLANT AUXILIARIES… … -To Heating System OrTo Atmosphere ^Impulse Of Steam Current Fig. 230.—Impulse Of Steam Current Di-rected Toward Induction Heater.
Steam power plants · Pumping machinery
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
