Steam power plant auxiliaries and accessories; (1922)
Croft, Terrell, 1880- ed, Dufflin, Daniel John, 1911- ed · New York, [etc] McGraw-Hill book company, Inc · leaf 254
type Very bad water 8.56.02.0 9 1 Medium muddy water Clear water little scale 6.52 2 Sec. 267] FEED-WATER HEATERS 233 Note.—The practice in heater manufacture is, however, to use a totaltray surface equal to about 3 to 4 times the horizontal sectional area ofthe shell at the plane at which the… … Fig. 240.—Blake-Knowles Open Exhaust-Steam Feed-Water Heater Using Inclined Trays. use more than six pans in a tier. The size of the water storage or settlingspace in the horizontal type varies from 0.25 to 0.4 the volume of theshell; and in the vertical type from 0.4 to 0.6. The filters occupy…
Steam power plants · Pumping machinery
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
