Steam power plant auxiliaries and accessories; (1922)
Croft, Terrell, 1880- ed, Dufflin, Daniel John, 1911- ed · New York, [etc] McGraw-Hill book company, Inc · leaf 312
Fig. 291.—Worthington Independent Jet Condenser. water-cooling is impracticable, due to an insufficient supply.(3) Evaporation cooling, in which a cooling effect is producedby the evaporation of streams of water trickling on the outersurfaces of metal tubes through which the exhaust steam ismade to… … Shield to Prevent Water From # Dripping Into ToAir AirPipe Pump Fig. 292.—Elementary Double-Flow (Two-Pass) Surface Condenser. Condenser Shell- Exhaust- Circulating Water ^faT leaves Condenser-..
Steam power plants · Pumping machinery
