Steam power plant auxiliaries and accessories; (1922)
Croft, Terrell, 1880- ed, Dufflin, Daniel John, 1911- ed · New York, [etc] McGraw-Hill book company, Inc · leaf 393
..--Main HeadersSingle-Sweep Tees—^ •Valves Steam Pipe V .Steam Pipesto Compound jf* to TurbinesEngine … Fig. 355.—Continuation Of Duplicate Headers X and Y, Fig. 354, Through Engine Room. 438. With The Unit-Group Arrangement (Fig. 356) eachengine is piped directly to an individual set of boilers, usuallyfour, as boilers A, B, C and D, or E, F, G and H, or /, J, Kand L. Equalizer pipes are, however,…
Steam power plants · Pumping machinery
